[TASK-3-6] Save_test_set(test_set)

by ADMIN 35 views

Overview

The save_test_set ADK tool is a critical component of the data processing pipeline, responsible for persisting extracted, structured, and tagged test question data into the Supabase database. This task involves implementing the save_test_set tool, which will handle the final stage of the pipeline: saving processed data.

Parent Epic

Epic 3: Tool Implementation (ADK Tool Functions)

Background / Why

The save_test_set tool is essential for storing and retrieving question sets. As per mvp_breakdown.md (line 33), this tool will utilize the upsert method from Supabase to insert or update data in the database.

  • [ ] T6 save_test_set(test_set) ― Supabase upsert (onConflict=["part_id","number"])

What to do / How

Fetch and Understand ADK Documentation

  • Use the MCP tool Context7 to fetch and understand ADK documentation from Agent Development Kit (ADK) Documentation.
  • Understand ADK documentation and how to use Tools and ToolContext, particularly for interacting with external services like Supabase.

Implement save_test_set Tool

  • Create/update the Python file for the tool (e.g., questions_extractor_agent/tools/database_tools.py or questions_extractor_agent/tools/save_tool.py, following tools/**.py convention from mvp_breakdown.md).
    • Define the save_test_set(test_set: dict, tool_context: ToolContext) function signature as specified in prd.md (Section 4.2).
      • Input: test_set (a dictionary containing the structured question data ready for DB insertion, conforming to the 7+2 table structure).
      • Input: tool_context (ADK ToolContext).

Supabase Integration

  • Utilize the supabase library to connect to the Supabase instance (credentials should be loaded from .env).
  • Implement upsert logic for each of the tables defined in prd.md (Section 5. Data Model):
    • test_forms
    • sections
    • parts
      • passage_sets
      • passages
      • questions (implement onConflict=["part_id","number"])
      • choices (implement onConflict=["question_id","label"])
      • tags
      • question_tags
    • Ensure data is inserted/updated in the correct order to satisfy foreign key constraints. Consider the relationships between tables (e.g., a question belongs to a part and passage_set).
    • Group database operations logically, potentially by passage_set, and perform bulk upserts within database transactions for efficiency and atomicity.
    • Adhere to the JSONB metadata size limit (less than 8MB per row) for tables like passage_sets and passages as noted in prd.md.

Return Values

  • The tool must return a dictionary as specified in prd.md (Section 4.2): {"status": "success" | "error", "message": "Descriptive message", "rows_upserted": integer_count}.

Unit Testing

  • Create unit tests in tests/tools/test_save_test_set.py (or similar, matching the tool's file location).
  • Mock Supabase client interactions using unittest.mock or a similar library.
    • Test successful data insertion for all tables.
    • Test successful data updates (idempotency) due to onConflict clauses for questions and choices.
    • Test correct handling of relationships and foreign keys.
    • Test error handling (e.g., database errors, malformed test_set data).
    • Verify the structure and content of the return values (status, message, rows_upserted).

Acceptance Criteria / AC

  • The save_test_set tool is implemented as an ADK Tool function.
  • The tool correctly upserts structured test data into all 9 Supabase tables (test_forms, sections, parts, passage_sets, passages, questions, choices, tags, question_tags).
  • onConflict constraints for questions (part_id, number) and choices (question_id, label) are correctly implemented and prevent duplicate entries while allowing updates.
  • The tool handles bulk operations efficiently, ideally grouped by passage_set and within transactions.
  • The tool returns the specified status, message, and rows_upserted count.
  • Unit tests for save_test_set are comprehensive and pass, covering successful operations, onConflict behavior, and error handling.
  • As per roadmap.md (Milestone Week 10), the implementation should support storing 1k dummy questions without duplicates, demonstrating robust onConflict and bulk handling.
  • Consider and test for pgBouncer connection limits if applicable during integration testing (as noted in mvp_breakdown.md for T6 tests).

Predefined Checklist

  • Code style unified (ruff/black/isort)
  • Type check (mypy | pyright)
  • Docstring & comments added, explaining the logic, especially for data mapping and Supabase interactions.
  • Test cases added (as detailed in "What to do / How" and "Acceptance Criteria").
  • Documentation updated (if applicable, e.g., notes on data structure expectations for test_set).

Related Materials

  • PRD: docs/prd.md (especially Sections 3.3, 4.2, 5)
  • Roadmap: docs/roadmap.md (Phase 4: Supabase I/O, Milestone Week 10)
  • MVP Breakdown: docs/mvp_breakdown.md (Task T6, line 33)
    Q&A: Implementing the save_test_set ADK Tool =====================================================

Q: What is the purpose of the save_test_set ADK tool?

A: The save_test_set ADK tool is responsible for persisting extracted, structured, and tagged test question data into the Supabase database. This is a critical step in the data processing pipeline, enabling the storage and future retrieval of question sets.

Q: What is the expected input for the save_test_set tool?

A: The expected input for the save_test_set tool is a dictionary containing the structured question data ready for DB insertion, conforming to the 7+2 table structure, and an ADK ToolContext.

Q: How does the save_test_set tool interact with Supabase?

A: The save_test_set tool utilizes the supabase library to connect to the Supabase instance and perform upsert operations on the specified tables.

Q: What are the key features of the save_test_set tool?

A: The key features of the save_test_set tool include:

  • Correctly upserting structured test data into all 9 Supabase tables
  • Implementing onConflict constraints for questions and choices
  • Handling bulk operations efficiently, ideally grouped by passage_set and within transactions
  • Returning the specified status, message, and rows_upserted count

Q: What are the acceptance criteria for the save_test_set tool?

A: The acceptance criteria for the save_test_set tool include:

  • The tool is implemented as an ADK Tool function
  • The tool correctly upserts structured test data into all 9 Supabase tables
  • onConflict constraints for questions and choices are correctly implemented
  • The tool handles bulk operations efficiently
  • The tool returns the specified status, message, and rows_upserted count
  • Unit tests for save_test_set are comprehensive and pass

Q: What is the predefined checklist for implementing the save_test_set tool?

A: The predefined checklist for implementing the save_test_set tool includes:

  • Code style unified (ruff/black/isort)
  • Type check (mypy | pyright)
  • Docstring & comments added, explaining the logic, especially for data mapping and Supabase interactions
  • Test cases added (as detailed in "What to do / How" and "Acceptance Criteria")
  • Documentation updated (if applicable, e.g., notes on data structure expectations for test_set)

Q: What are the related materials for implementing the save_test_set tool?

A: The related materials for implementing the save_test_set tool include:

  • PRD: docs/prd.md (especially Sections 3.3, 4.2, 5)
  • Roadmap: docs/roadmap.md (Phase 4: Supabase I/O, Milestone Week 10)
  • MVP Breakdown: docs/mvp_breakdown.md (Task T6, line 33)

: What is the expected outcome of implementing the save_test_set tool?

A: The expected outcome of implementing the save_test_set tool is a robust and efficient data processing pipeline that can store and retrieve question sets correctly.
